The Cholesterol Meter is a portable, battery operated in vitro diagnostic medical device and it is working with Cholesterol Test Strips. Cholesterol Meter is used for quantitative determination of cholesterol in capillary blood, venous blood, plasma, arterial blood and serum using Amperometric principle. Cholesterol measurements are used in the diagnosis and treatment of disorders involving excess cholesterol in the blood and lipid and lipoprotein metabolism disorders. Simply add a drop of blood to test strip, and the result is displayed on the screen in 20 seconds. The device is suitable for testing cholesterol with blood obtained from alternative sites like forearm, upper arm, hand, tigh, calf or fingers. It is used outside the body and suitable for professional use.

Test Principle	Determination of Cholesterol Parameter (HDL & LDL)in fresh Capillary, Venous, Arterial blood, Serum & Plasma
Assay Method	Amperometric Biosensor
Sample	Capillary, Venous, Arterial blood, Serum & Plasma
Sample Size	1.5 µL (1500 nanoliters)
Test Time	20 Seconds
Memory	500 Previous Readings with date and time
Result Range	100 to 400 mg/dL (2.5 to 10 mmol/L)
Measurement Units	mg/dL, mmol/L
Fill Detection	Automatic
Automatic Shutoff	After 5 seconds, depending on operating status
Battery Life	Approximately 1000 tests
Operating Temperature	2 C to 50 C (35.6 F to 122 F)
Operating Relative – Humidity	10 % to 95 % (non-condensing)
Strips Storage Temperature	0 C to 50 C (32 F to 122 F) (Do not refrigerate)
Strips Shelf Life	24 Months
Power Source	Two 3 volt lithium batteries (CR2032), replaceable
Display Size (mm)	48 (diagonally) LCD
Meter Size (cm)	Length 8.06 x Width 5.4 x Depth 1.7
Weight	54.5 grams (with batteries)
Data Port	Serial Port RS-232 with 2.5mm Jack and BT(Optional)
Strip Ejection	Yes
Construction	Handheld
Meter Warranty	5 Years
Average	7-day, 14-day or 30-day averaging
